| Standard Specification | M08D-II |
|---|---|
| Max. machinable dia. | Φ 280mm |
| Main spindle speed | 200~4,500 min-1 |
| No. of turret stations | 12 station turret |
| Rapid traverse rate | X : 24m/min Z :27m/min |
| Main Spindle motor | 7.5/11 kW |
| Width x Depth x Height | 2,330 x 1,865 x 1,750mm |
| Weight | 5,000 Kg. |
| Standard Specification | M08DY-II |
|---|---|
| Max. machinable dia. | Φ 280 mm/ Φ 65 mm (Barstock) |
| Main spindle speed | 200~4,500 min-1 |
| No. of turret stations | 12-station turret |
| Rapid traverse rate | X: 24m/min Y: 12m/min Z:27m/min |
| Main Spindle motor | 7.5/11 kW |
| Width x Depth x Height | 2,330 x 1,865 x 1,930mm |
| Weight | 5,200 Kg. |
| Standard Specification | M08SY-II |
|---|---|
| Max. machinable dia. | Φ 280 mm |
| Main spindle speed | 200~4,500 min-1 |
| Back spindle speed | 200~4,500 min-1 |
| No. of turret stations | 12 station turret |
| Rapid traverse rate | X : 24m/min Y :12m/min Z : 27m/min A : 30m/min |
| Main Spindle motor | 7.5/11 kW |
| Width x Depth x Height | 2,470 x 1,865 x 1,930mm |
| Weight | 5,900 Kg. |
| Standard Specification | Mi06JC-II |
|---|---|
| Max. machinable dia. | Φ 220/ Φ 42 (Bar work) mm |
| Main spindle speed | 200~4,500 min-1 |
| No. of turret stations | 200~7,000 min-1 |
| Rapid traverse rate | (X,Z:24m/min) |
| Main Spindle motor | 5.5/7.5 kW |
| Width x Depth x Height | 1,165 x 1,460 x 1,600mm |
| Weight | 2,380 Kg. |
| Standard Specification | Mi06JCM-II |
|---|---|
| Max. machinable dia. | Φ 220mm/Φ 42(B or work)mm |
| Main spindle speed | 200~4,500 min-1 |
| No. of turret stations | 8 station turret |
| Rapid traverse rate | X,Z : 24m/min |
| Main Spindle motor | 5.5/7.5 kW |
| Width x Depth x Height | 1,265 x 1,560 x 1,650mm |
| Weight | 2,230 Kg. |
| Standard Specification | Mi06J-II |
|---|---|
| Max. machinable dia. | Φ 260mm/Φ 51(B or work)mm |
| Main spindle speed | 200~4,500 min-1 |
| No. of turret stations | 8 station turret |
| Rapid traverse rate | X: 24m/min Z : 27m/min |
| Main Spindle motor | 5.5/7.5 kW |
| Width x Depth x Height | 1,865 x 1,673 x 1,600mm |
| Weight | 3,330 Kg. |
| Standard Specification | Mi08J-II |
|---|---|
| Max. machinable dia. | Φ 280mm |
| Main spindle speed | 200~4,000 min-1 |
| No. of turret stations | 8 station turret |
| Rapid traverse rate | X : 24m/min Z :27m/min |
| Main Spindle motor | 9/11 kW |
| Width x Depth x Height | 1,690 x 1,570 x 1,600mm |
| Weight | 3,600 Kg. |
| Standard Specification | Mi08JL5-II |
|---|---|
| Max. machinable dia. | Φ 280mm/Φ65 mm(Barstock) |
| Main spindle speed | 200~4,000 min-1 |
| No. of turret stations | 8 station turret |
| Rapid traverse rate | X : 24m/min Z :27m/min |
| Main Spindle motor | 9/11 kW |
| Width x Depth x Height | 2,170 x 1,778 x 1,600mm |
| Weight | 3,430 Kg. |
| Standard Specification | TMA 8J |
|---|---|
| Linear Scale | - |
| Chuck size of main work spindle | 8” |
| Chuck size of back work spindle | 6” |
| Main work spindle speed | 5,000 min-1 |
| Back work spindle speed | 5,000 min-1 |
| B-axis index angle | -15°~195° |
| B-axis least index angle | 0.001° (positioning) |
| B-axis index angle by coupling | 5° |
| Tool storage capacity | 30 |
| Width x Depth x Height | 3,700 x 2,126 x 2,250 mm |
| Weight | 8,500 Kg. |
| DESCRIPTION | PL 500AW 20″ Wheel | |
|---|---|---|
| Travel | X/Z axis travel |
360/680 |
| X/Z rapid traverse rate |
20/24 | |
| Chuck | Chuck size |
20" |
| Capacity | Swing over bed |
830 |
| Recom. turning diameter |
508(20" Wheel) | |
| Swing over cross slide |
720 | |
| Max. turning diameter |
670 | |
| Maximum turning length |
710 | |
| Spindle | Spindle speed |
3000 |
| Spindle nose |
A2-8 | |
| Spindle bore diameter |
90 | |
| Spindle motor (Cont./Max) |
37/30 | |
| Travels | feed motor(X/Z) |
4/7 |
| Turret | Number of tool stations |
12 |
| Turret index time(next station swivel time) |
0.25 | |
| Shank size for square tool |
32x32 | |
| Shank diameter for boring bar |
60 | |
| Machine | Req. floor space(L×W×H) |
3,845(5,056)×2,090 |
| Machine weight |
2,195 | |
| Coolant tank capacity |
7700 | |
| Electric power supply | |
60 |
| Controller | |
Fanuc Oi-TF |
| Standard Specification | B0125-III |
|---|---|
| Max. machinable dia. | Φ 12mm |
| Main spindle speed | 200~12,000 min-1 |
| Back spindle speed | 200～12,000min-1 |
| Total number of tools | 21 |
| Rapid traverse rate | 32m/min (X1:24m/min) |
| Main Spindle motor | 1.5/2.2 kW |
| Width x Depth x Height | 1,655 x 1,135 x 1,700mm |
| Weight | 2,000 Kg. |
| Standard Specification | B0203-III |
|---|---|
| Max. machinable dia. | Φ 20mm |
| Main spindle speed | 200~10,000 min-1 |
| Back spindle speed | - |
| Total number of tools | 13 |
| Rapid traverse rate | 32m/min (X1:24m/min |
| Main Spindle motor | 2.2/3.7 kW |
| Width x Depth x Height | 1,590 x 1,125 x 1,700mm |
| Weight | 1,500 Kg. |
| Standard Specification | B0204-III |
|---|---|
| Max. machinable dia. | Φ 20mm |
| Main spindle speed | 200~10,000 min-1 |
| Back spindle speed | 200~12,000 min-1 |
| Total number of tools | 17 |
| Rapid traverse rate | 32m/min (X1:24m/min) |
| Main Spindle motor | 2.2/3.7 kW |
| Width x Depth x Height | 1,655 x 1,135 x 1,700mm |
| Weight | 1,950 Kg. |
| Standard Specification | B0205-III |
|---|---|
| Max. machinable dia. | Φ 20mm |
| Main spindle speed | 200~10,000 min-1 |
| Back spindle speed | 200~12,000 min-1 |
| Total number of tools | 21 |
| Rapid traverse rate | 32m/min (X1:24m/min) |
| Main Spindle motor | 2.2/3.7 kW |
| Width x Depth x Height | 1,655 x 1,135 x 1,700mm |
| Weight | 2,000 Kg. |
| Standard Specification | B0206-III |
|---|---|
| Max. machinable dia. | Φ 20mm |
| Main spindle speed | 200~10,000 min-1 |
| Back spindle speed | 200~12,000 min-1 |
| Total number of tools | 25 |
| Rapid traverse rate | 32m/min (X1:24m/min. Y2:15m/min)) |
| Main Spindle motor | 2.2/3.7 kW |
| Width x Depth x Height | 1,655 x 1,135 x 1,700mm |
| Weight | 2,050 Kg. |
| Standard Specification | B0265-III |
|---|---|
| Max. machinable dia. | Φ 26mm |
| Main spindle speed | 200~10,000 min-1 |
| Back spindle speed | 200~10,000 min-1 |
| Total number of tools | 27 |
| Rapid traverse rate | 35m/min (X1,Y1,Y2:24m/min) (Y2: Only for 6-axis machine) |
| Main Spindle motor | 3.7/5.5 kW |
| Number of axis | 5 |
| Width x Depth x Height | 2,630 x 1,270 x 1,970mm |
| Weight | 4,000 Kg. |
| Standard Specification | B0265V-III |
|---|---|
| Max. machinable dia. | Φ 26mm |
| Main spindle speed | 200~10,000 min-1 |
| Back spindle speed | 200~10,000 min-1 |
| Total number of tools | 22 |
| Rapid traverse rate | 35m/min (X1,Y1,Y2:24m/min) (Y2: Only for 6-axis machine) |
| Main Spindle motor | 3.7/5.5 kW |
| Number of axis | 5 |
| Width x Depth x Height | 2,630 x 1,270 x 1,970mm |
| Weight | 4,000 Kg. |
| Standard Specification | B0265-III |
|---|---|
| Max. machinable dia. | Φ 26mm |
| Main spindle speed | 200~10,000 min-1 |
| Back spindle speed | 200~10,000 min-1 |
| Total number of tools | 31 |
| Rapid traverse rate | 35m/min (X1,Y1,Y2:24m/min) (Y2: Only for 6-axis machine) |
| Main Spindle motor | 3.7/5.5 kW |
| Number of axis | 6 |
| Width x Depth x Height | 2,630 x 1,270 x 1,970mm |
| Weight | 4,000 Kg. |
| Standard Specification | B0265V-III |
|---|---|
| Max. machinable dia. | Φ 26mm |
| Main spindle speed | 200~10,000 min-1 |
| Back spindle speed | 200~10,000 min-1 |
| Total number of tools | 26 |
| Rapid traverse rate | 35m/min (X1,Y1,Y2:24m/min) (Y2: Only for 6-axis machine) |
| Main Spindle motor | 3.7/5.5 kW |
| Number of axis | 6 |
| Width x Depth x Height | 2,630 x 1,270 x 1,970mm |
| Weight | 4,000 Kg. |
| Standard Specification | B0325- III |
|---|---|
| Max. machinable dia. | Φ 32mm |
| Main spindle speed | 200~8,000 min-1 |
| Back spindle speed | 200~8,000 min-1 |
| Total number of tools | 27 |
| Rapid traverse rate | 32m/min (X1,Y1,Y2:24m/min) (Y2: Only for 6-axis machine) |
| Main Spindle motor | 3.7/5.5 kW |
| Width x Depth x Height | 2,630 x 1,270 x 1,970mm |
| Number of axis | 5 |
| Weight | 4,000 Kg. |
| Standard Specification | B0325V-III |
|---|---|
| Max. machinable dia. | Φ 32mm |
| Main spindle speed | 200~8,000 min-1 |
| Back spindle speed | 200~8,000 min-1 |
| Total number of tools | 22 |
| Rapid traverse rate | 32m/min (X1,Y1,Y2:24m/min) (Y2: Only for 6-axis machine) |
| Main Spindle motor | 3.7/5.5 kW |
| Width x Depth x Height | 2,630 x 1,270 x 1,970mm |
| Number of axis | 5 |
| Weight | 4,000 Kg. |
| Standard Specification | B0326- III |
|---|---|
| Max. machinable dia. | Φ 32mm |
| Main spindle speed | 200~8,000 min-1 |
| Back spindle speed | 200~8,000 min-1 |
| Total number of tools | 31 |
| Rapid traverse rate | 32m/min (X1,Y1,Y2:24m/min) (Y2: Only for 6-axis machine) |
| Main Spindle motor | 3.7/5.5 kW |
| Width x Depth x Height | 2,630 x 1,270 x 1,970mm |
| Number of axis | 6 |
| Weight | 4,000 Kg. |
| Standard Specification | B0326V-III |
|---|---|
| Max. machinable dia. | Φ 32mm |
| Main spindle speed | 200~8,000 min-1 |
| Back spindle speed | 200~8,000 min-1 |
| Total number of tools | 26 |
| Rapid traverse rate | 32m/min (X1,Y1,Y2:24m/min) (Y2: Only for 6-axis machine) |
| Main Spindle motor | 3.7/5.5 kW |
| Width x Depth x Height | 2,630 x 1,270 x 1,970mm |
| Number of axis | 6 |
| Weight | 4,000 Kg. |
| Standard Specification | B0385-III |
|---|---|
| Max. machinable dia. | Φ 32mm |
| Main spindle speed | 200~6,000 min-1 |
| Back spindle speed | 200~7,000 min-1 |
| Total number of tools | 26 |
| Rapid traverse rate | 32m/min (X1,Y1:24m/min) |
| Main Spindle motor | 7.5/11 kW |
| Width x Depth x Height | 2,770 x 1,515 x 2,050mm |
| Number of axis | 5 |
| Weight | 4,850 Kg. |
| Standard Specification | B0385V-III |
|---|---|
| Max. machinable dia. | Φ 38mm |
| Main spindle speed | 200~6,000 min-1 |
| Back spindle speed | 200~7,000 min-1 |
| Total number of tools | 21 |
| Rapid traverse rate | 32m/min (X1,Y1:24m/min) |
| Main Spindle motor | 7.5/11 kW |
| Width x Depth x Height | 2,770 x 1,515 x 2,050mm |
| Weight | 4,850 Kg. |
| Standard Specification | B0386-III |
|---|---|
| Max. machinable dia. | Φ 32mm |
| Main spindle speed | 200~6,000 min-1 |
| Back spindle speed | 200~7,000 min-1 |
| Total number of tools | 29 |
| Rapid traverse rate | 32m/min (X1,Y1,Y2:24m/min) |
| Main Spindle motor | 7.5/11 kW |
| Width x Depth x Height | 2,630 x 1,270 x 1,970mm |
| Number of axis | 6 |
| Weight | 4,850 Kg. |
| Standard Specification | B0385L-III |
|---|---|
| Max. machinable dia. | Φ 38mm |
| Main spindle speed | 200~6,000 min-1 |
| Back spindle speed | 200~7,000 min-1 |
| Total number of tools | 26 |
| Rapid traverse rate | 32m/min (X1,Y1:24m/min) |
| Main Spindle motor | 7.5/11 kW |
| Width x Depth x Height | 2,770 x 1,515 x 2,050mm |
| Weight | 4,850 Kg. |
| Standard Specification | S205-II |
|---|---|
| Max. machinable dia. | Φ 20mm |
| Main spindle speed | 200~10,000 min-1 |
| Back spindle speed | 200~12,000 min-1 |
| Total number of tools | 24 |
| Rapid traverse rate | Z1,Z2,X2:32m/min, X1,Y1:24m/min, Y2:15m/min(Only for S206) |
| Main Spindle motor | 2.2/3.7 kW |
| Number of axis | 5 |
| Width x Depth x Height | 2,110 x 1,200 x 1,885mm |
| Weight | 3,200 Kg. |
| Standard Specification | S206-II |
|---|---|
| Max. machinable dia. | Φ 20mm |
| Main spindle speed | 200~10,000 min-1 |
| Back spindle speed | 200~12,000 min-1 |
| Total number of tools | 28 |
| Rapid traverse rate | Z1,Z2,X2:32m/min, X1,Y1:24m/min, Y2:15m/min(Only for S206) |
| Main Spindle motor | 2.2/3.7 kW |
| Number of axis | 6 |
| Width x Depth x Height | 2,110 x 1,200 x 1,885mm |
| Weight | 3,300 Kg. |
| Standard Specification | VA3 |
|---|---|
| X/Y/Z/ axis stroke | 400x300x250 mm |
| Table size | 840 x 380 mm |
| Max. load on table | 150 Kg. |
| Spindle speed | 200~20,000 min-1 |
| Spindle motor | 9.0/3.7 kW |
| Tool shank | JIS B 6339-1998 BT30 |
| Retention knob | MAS403-1982 P30T-1 |
| Width x Depth x Height | 1,300 x 2,270 x 2,310 mm |
| Weight | 3,300 Kg. |
| Standard Specification | VA4 |
|---|---|
| X/Y/Z/ axis stroke | 720x510x460 mm |
| Table size | 850 x 510 mm |
| Max. load on table | 800 Kg. |
| Spindle speed | 100~10,000 min-1 |
| Spindle motor | 11/15 kW |
| Tool shank | BIG PLUS BBT 40 |
| Retention knob | MAS4003-1982 P40T-1 |
| Width x Depth x Height | 2,403 x 2,763 x 2,618 mm |
| Weight | 5,500 Kg. |
| SIZE (in mm) | GR “0” |
|---|---|
| 250 x 250 | 3.5 |
| 300 x 300 | 3.5 |
| 400 x 400 | 4.5 |
| 630x 400 | 5.0 |
| 630 x 630 x 80 | 5.0 |
| 1000 x 630 x 150 | 6.0 |
| 1000 x 1000 x 150 | 7.0 |
| 1200 x 900 x 150 | 7.0 |
| 1600 x 1000 x 200 | 8.0 |
| 2000 x 1000 x 200 | 9.5 |
| SIZE (in mm) | GR “1” |
|---|---|
| 250 x 250 | 7.0 |
| 300 x 300 | 7.0 |
| 400 x 400 | 9.0 |
| 630x 400 | 10 |
| 630 x 630 | 10 |
| 1000 x 630 | 12 |
| 1000 x 1000 | 14 |
| 1200 x 900 | 14 |
| 1600 x 1000 | 16 |
| 2000 x 1000 | 19 |
